ASTM A193 B6X Industrial Fasteners, ASTM A193 Gr B6X Screw, SS ASTM A193 B6X Washer, ASTM A193 B6X Stud Bolts, ASTM A193 B6X Fastener, ASTM A193 B6X Hex Head Bolt, Stainless Steel ASTM A193 Grade B6X High Temperature Fastener, Best Deals on ASTM A193 B6X Bolts, Stainless Steel ASTM A193 B6X Stud Supplier in India.
Kalpataru Piping Solutions is a prominent manufacturer of Stainless Steel ASTM A193 B6X Fasteners, which is shaped by welding the seam or rolling plate. These Stainless Steel ASTM A193 B6X Nuts are widely used across different industries such as in petrochemicals, pharmaceuticals, oil and gas, pulp and paper industrialized, etc. These Stainless Steel ASME SA 193 B6X Bolts are also used in heat exchangers, industrial boilers, nuclear power, process pipe lines and thermal power generation among others. As one of the leading suppliers, we emphases our power in giving hard to find sizes in Stainless Steel ASTM A193 B6X Screws for applications in the food processing industries. Stainless Steel ASME SA 193 B6X Washers commits to a collection of welding procedures such as seam and spot welding that make amalgamation of faying camouflages. Stainless Steel ASTM A193 B6X Hex Head Screws offers heat to practice the weld is shaped by the electrical resistance of material joint with the time and power which is used to take hold of the materials as one in welding. In the meantime, Stainless Steel ASME SA 193 B6X Hex Head Bolts are at large manufactured to one of international and national industrial standards. A great deal of industrial and government standards is existent for the making of Stainless Steel ASTM A193 B6X Hex Head Nuts, which are highly appreciated for their seamless finish, rigid construction and abrasion resistance.
Stainless Steel ASTM A193 Grade B6X Star Washer, ASTM A193 B6X Lock Washer, ASTM A193 B6X U Bolts Dealer, High Quality ASTM A193 B6X Hex Head Screw, ASTM A193 B6X Stud Bolts, ASTM A193 B6X Socket Head Cap Screw, SS ASTM A193 B6X High Temperature Spring Washers, Large Selection of ASTM A193 B6X Hex Nuts, ASTM A193 B6X Machine Screw, Stainless Steel ASTM A193 B6X High Temperature Eye Bolts Exporter.
ASTM A193 B6X Fasteners Specification
ASTM A193 B6X Fasteners Standard
| Hexagon Bolt / Set Screws | Stud Bolt | Hexagon Nuts | Socket Cap screws |
| DIN 931 | BS4882 | DIN 934 | DIN 912 |
| DIN 933 | DIN 976 | BS 1768 | DIN 6912 |
| BS 1768 | BS 1769 | DIN 7984 | |
| UNI 5731 | BS 1083 | ANSI B18.3 | |
| UNI 5739 | BS 3692 | ISO 4762 | |
| ISO 4014 | ISO 4032 | UNI 5931 | |
| ISO 4017 | ISO 4033 | BS 2470 | |
| BS 1769 | ANSI B18.2.2 | BS 4168 | |
| BS 3692 | |||
| ANSI B18.2.1 | |||
| Socket & Slotted Set Screws | Socket & Slotted Countersunk Screws | Studs | Washers |
| DIN 913 | DIN 963 | DIN 938 | DIN 125 |
| DIN 914 | DIN 7991 | DIN 939 | DIN 9021 |
Types of ASTM A193 B6X Fasteners
ASTM A193 B6X Nuts
ASTM A193 B6X Bolts
ASTM A193 B6X Screws
ASTM A193 B6X Washers
ASTM A193 B6X Stud Bolts
ASTM A193 B6X Anchor Bolts
ASTM A193 B6X Threaded Rod
ASTM A193 B6X Stud
ASTM A193 B6X Fasteners Price List
We offer wide range of industrial ASTM A193 B6X Fasteners that in compliance with IS, BS and DIN standards at best market prices in India. To know more about the latest price of SS ASTM A193 B6X Fasteners Please Call +91 22-66337137 or Send an Email to info@flangesbolts.com
Dimension Schedule Of ASTM A193 B6X Hex Bolts
| NOMINAL SIZE (D) | BODY DIAMETER | HEAD THICKNEASTM A193 | ACROASTM A193 THE FLATS | ACROASTM A193 CORNERS | ||||
|---|---|---|---|---|---|---|---|---|
| D (MAX) | D (MIN) | H (MAX) | H (MIN) | F (MAX) | F (MIN) | C (MAX) | C (MIN) | |
| m10 | 10.00 | 9.78 | 6.63 | 6.17 | 17.00 | 15.73 | 18.48 | 17.77 |
| m12 | 12.00 | 11.73 | 7.76 | 4.24 | 19.00 | 17.73 | 20.78 | 20.03 |
| m14 | 14.00 | 13.73 | 9.09 | 8.51 | 22.00 | 20.67 | 24.25 | 23.35 |
| m16 | 16.00 | 15.73 | 10.32 | 9.68 | 24.00 | 23.67 | 27.71 | 26.75 |
| m20 | 20.00 | 19.67 | 12.88 | 12.12 | 30.00 | 29.16 | 34.64 | 32.95 |
| m24 | 24.00 | 23.67 | 15.44 | 14.56 | 36.00 | 35.00 | 41.57 | 39.55 |
| m30 | 30.00 | 29.67 | 19.48 | 17.92 | 46.00 | 45.00 | 53.12 | 50.85 |
| m36 | 36.00 | 35.61 | 23.38 | 21.63 | 55.00 | 53.80 | 63.51 | 60.79 |
| m42 | 42.00 | 41.38 | 26.97 | 25.03 | 65.00 | 62.90 | 75.06 | 71.71 |
| m48 | 48.00 | 47.38 | 31.07 | 28.93 | 75.00 | 72.60 | 86.60 | 82.76 |
| m56 | 56.00 | 55.26 | 36.2 | 33.80 | 85.00 | 82.20 | 98.15 | 93.71 |
| m64 | 64.00 | 63.26 | 41.32 | 38.68 | 95.00 | 91.80 | 109.70 | 104.65 |
| m72 | 72.00 | 71.26 | 46.45 | 43.55 | 105.00 | 101.40 | 121.24 | 115.60 |
| m80 | 80.00 | 79.26 | 51.58 | 48.42 | 115.00 | 111.00 | 132.72 | 126.54 |
| m90 | 90.00 | 89.13 | 57.74 | 54.26 | 130.00 | 125.50 | 150.11 | 143.07 |
| m100 | 90.00 | 99.13 | 63.9 | 60.10 | 145.00 | 140.00 | 167.43 | 159.60 |
ASTM A193 B6X Stud Bolts Torque Chart
| Nominal Diameter(Inches) | Threads (Inches) | Torque Foot-LBS (Dry) | Torque Foot-LBS (Lubricated) |
|---|---|---|---|
| 1/4″ | 20 | 7.4 | 5.5 |
| 28 | 8.4 | 6.3 | |
| 5/16″ | 18 | 15.1 | 11.4 |
| 24 | 16.8 | 12.6 | |
| 3/8″ | 16 | 26.9 | 20.2 |
| 24 | 30.4 | 22.8 | |
| 7/16″ | 14 | 43.0 | 32.3 |
| 20 | 48.0 | 36.0 | |
| 1/2″ | 13 | 65.6 | 49.1 |
| 20 | 73.9 | 55.4 | |
| 9/16″ | 12 | 94.5 | 71.0 |
| 18 | 105.5 | 79.1 | |
| 5/8″ | 11 | 130.5 | 97.9 |
| 18 | 147.8 | 110.9 | |
| 3/4″ | 10 | 232 | 174 |
| 16 | 258 | 194 | |
| 7/8″ | 9 | 373 | 280 |
| 14 | 412 | 309 | |
| 1″ | 8 | 560 | 420 |
| 14 | 628 | 471 | |
| 1-1/4″ | 7 | 975 | 730 |
| 12 | 1079 | 809 | |
| 1-1/2″ | 6 | 1696 | 1271 |
| 12 | 1908 | 1430 |
ASTM A193 B6X Heavy Hex Bolts Dimensions
| Diameter (D) | Body Diameter (D) | Across the Flats (F) | Across the Corners © | Head Height (H) | Thread Lengths (T) | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| MAX | MIN | MAX | MIN | MAX | MIN | MAX | MIN | < 6” | > 6” | |
| 1/2 | 0.515 | 0.482 | 0.875 | 0.85 | 1.01 | 0.969 | 0.364 | 0.302 | 1.25 | 1.5 |
| 5/8 | 0.642 | 0.605 | 1.062 | 1.031 | 1.227 | 1.175 | 0.444 | 0.378 | 1.5 | 1.75 |
| 3/4 | 0.768 | 0.729 | 1.25 | 1.212 | 1.443 | 1.383 | 0.524 | 0.455 | 1.75 | 2 |
| 7/8 | 0.895 | 0.852 | 1.438 | 1.394 | 1.66 | 1.589 | 0.604 | 0.531 | 2 | 2.25 |
| 1 | 1.022 | 0.976 | 1.625 | 1.575 | 1.876 | 1.796 | 0.7 | 0.591 | 2.25 | 2.5 |
| 1 1/8 | 1.149 | 1.098 | 1.812 | 1.756 | 2.093 | 2.002 | 0.78 | 0.658 | 2.5 | 2.75 |
| 1 1/4 | 1.277 | 1.223 | 2 | 1.938 | 2.309 | 2.209 | 0.876 | 0.749 | 2.75 | 3 |
| 1 3/8 | 1.404 | 1.345 | 2.188 | 2.119 | 2.526 | 2.416 | 0.94 | 0.81 | 3 | 3.25 |
| 1 1/2 | 1.531 | 1.47 | 2.375 | 2.3 | 2.742 | 2.622 | 1.036 | 0.902 | 3.25 | 3.5 |
| 1 3/4 | 1.785 | 1.716 | 2.75 | 2.662 | 3.175 | 3.035 | 1.196 | 1.054 | 3.75 | 4 |
| 2 | 2.039 | 1.964 | 3.125 | 3.025 | 3.608 | 3.449 | 1.388 | 1.175 | 4.25 | 4.5 |
| 2 1/4 | 2.305 | 2.214 | 3.5 | 3.388 | 4.041 | 3.862 | 1.548 | 1.327 | 4.75 | 5 |
| 2 1/2 | 2.559 | 2.461 | 3.875 | 3.75 | 4.474 | 4.275 | 1.708 | 1.479 | 5.25 | 5.5 |
| 2 3/4 | 2.827 | 2.711 | 4.25 | 4.112 | 4.907 | 4.688 | 1.869 | 1.632 | 5.75 | 6 |
| 3 | 3.081 | 2.961 | 4.625 | 4.475 | 5.34 | 5.102 | 2.06 | 1.815 | 6.25 | 6. |
ASTM A193 B6X Stainless Steel Bolts Weight Chart
| MM THREADS AS PER IS 1363/67 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| APPROXIMATE WEIGHT IN KGS FOR 100 NOS | ||||||||||
| LENGTH | DIAMETER | |||||||||
| M 5 | M 6 | M 8 | M 10 | M 12 | M 14 | M 16 | M 18 | M 20 | M 22 | |
| 16 mm | 0.448 | 0.743 | 1.590 | 3.211 | ||||||
| 20 mm | 0.598 | 0.812 | 1.711 | 3.411 | 4.892 | |||||
| 25 mm | 0.660 | 0.897 | 1.871 | 3.660 | 5.252 | 8.170 | ||||
| 30 mm | 0.737 | 1.010 | 2.070 | 3.912 | 5.574 | 9.690 | 10.707 | 18.657 | ||
| 35 mm | 0.804 | 1.120 | 2.271 | 4.223 | 5.974 | 10.000 | 11.416 | 16.026 | 19.608 | |
| 40 mm | 0.881 | 1.230 | 2.470 | 4.533 | 6.410 | 10.288 | 12.107 | 16.667 | 20.747 | |
| 45 mm | 0.958 | 1.340 | 2.671 | 4.840 | 6.859 | 10.504 | 12.821 | 17.241 | 21.739 | |
| 50 mm | 1.030 | 1.450 | 2.870 | 5.155 | 7.299 | 11.261 | 13.624 | 17.857 | 22.727 | 28.409 |
| 55 mm | 1.560 | 3.071 | 5.464 | 7.740 | 11.628 | 14.409 | 18.868 | 23.810 | 30.120 | |
| 60 mm | 1.670 | 3.270 | 5.774 | 8.183 | 12.255 | 15.244 | 20.000 | 25.126 | 32.051 | |
| 65 mm | 1.781 | 3.472 | 6.083 | 8.621 | 12.626 | 16.026 | 21.008 | 26.455 | 34.014 | |
| 70 mm | 1.890 | 3.671 | 6.394 | 9.058 | 12.987 | 16.835 | 22.124 | 27.778 | 35.461 | |
| 75 mm | 2.000 | 3.873 | 6.702 | 9.506 | 13.228 | 17.606 | 23.256 | 29.070 | 39.063 | |
| 80 mm | 2.111 | 4.072 | 7.013 | 10.000 | 13.889 | 18.248 | 24.510 | 30.303 | 40.000 | |
| 90 mm | 4.472 | 7.634 | 10.917 | 14.925 | 19.841 | 26.042 | 33.113 | 41.667 | ||
| 100 mm | 4.873 | 8.251 | 11.820 | 16.340 | 21.459 | 27.778 | 35.714 | 46.296 | ||
| 110 mm | 8.881 | 12.723 | 17.730 | 23.041 | 31.250 | 38.168 | 47.170 | |||
| 120 mm | 9.506 | 13.624 | 18.797 | 24.631 | 32.895 | 40.984 | 50.000 | |||
| 130 mm | 10.101 | 14.535 | 20.000 | 26.316 | 34.722 | 43.478 | 52.632 | |||
| 140 mm | 10.707 | 15.432 | 20.833 | 27.933 | 35.461 | 46.296 | 55.556 | |||
| 150 mm | 11.312 | 16.340 | 22.222 | 29.412 | 37.594 | 48.544 | 58.824 | |||
| 160 mm | 11.905 | 17.241 | 24.272 | 31.056 | 40.984 | 50.505 | 61.728 | |||
| 170 mm | 12.500 | 18.116 | 32.680 | 53.191 | 64.935 | |||||
| 180 mm | 13.123 | 19.011 | 26.882 | 34.247 | 55.556 | 67.568 | ||||
| 190 mm | 13.736 | 19.920 | 35.971 | 58.140 | 70.423 | |||||
| 200 mm | 14.327 | 20.833 | 29.586 | 37.594 | 49.020 | 60.976 | 73.529 | |||
| 220 mm | 15.528 | 22.624 | 40.650 | 65.789 | 79.365 | |||||
| 240 mm | 16.722 | 24.510 | 43.860 | 71.429 | 84.746 | |||||
| 250 mm | 17.301 | 25.381 | 45.455 | 74.627 | 87.719 | |||||
| 260 mm | 17.921 | 26.316 | 47.170 | 76.923 | 90.909 | |||||
| 280 mm | 19.157 | 28.090 | 50.505 | 81.967 | 98.039 | |||||
| 300 mm | 20.325 | 29.940 | 53.763 | 87.719 | 104.167 | |||||
| 320 mm | 31.646 | 56.818 | 92.593 | |||||||
| 340 mm | 33.557 | 60.241 | 98.039 | |||||||
| 360 mm | 35.211 | 63.291 | 104.167 | |||||||
| 380 mm | 37.037 | 66.667 | 108.696 | |||||||
| 400 mm | 39.063 | 69.444 | 113.636 | |||||||
Chemical Composition of ASTM A193 B6X Fasteners
| Grade | C | Mn | P | S | Si | Cr |
| ASTM A193 B6X | 0 - 0.15% | 0 - 1.00% | 0 - 0.040% | 0 - 0.03% | 0 - 1.00% | 11.5 - 13.5% |
Mechanical Properties of ASTM A193 B6X Fasteners
| Grade | Diameter | Tensile Strength | Yield Strength | Elongation | Reduction | Hardness |
|---|---|---|---|---|---|---|
| Grade B6X | Up to M100, inclusive | 620 | 485 | 16 | 50 | 26 HRC |
Other Types of ASTM A193 B6X Fasteners
ASTM A193 B6X High Temperature Fastener
ASTM A193 B6X Bolts
ASTM A193 Grade B6X Full Threaded Bolt
ASTM A193 B6X High Temperature Stud Bolts
SS ASTM A193 B6X Hex Nuts
ASTM A193 Grade B6X Washer
High Temperature A193 B6X Studs Stockist
Stainless Steel ASTM A193 B6X Screw Supplier
ASTM A193 B6X High Temperature Wing Nut
ASTM A193 B6X Lock Washer
ASTM A193 B6X Half Threaded Bolt
ASTM A193 B6X Machine Bolt
ASTM A193 B6X High Temperature Stud
ASTM A193 B6X High Temperature Anchor Bolt
SS ASTM A193 B6X Hex Head Screw Exporter
ASTM A193 B6X Hex Cap Screw
ASTM A193 B6X Hanger Bolt
ASTM A193 B6X Strut Bolts
ASTM A193 B6X Point Flange Bolts
ASTM A193 B6X Mushroom Head Square Neck Bolts
SS ASTM A193 B6X Nuts Specification
ASTM A193 B6X Socket Head Cap Screw
ASTM A193 B6X Castle Nuts
ASTM A193 B6X Spring Washer
ASTM A193 B6X SS Socket Set Screws
ASTM A193 B6X Hex Head Bolt Manufacturer
ASTM A193 B6X SS Fender Washer Distributor
Stainless Steel ASTM A193 B6X Dome Washer
ASTM A193 B6X Industrial Fastener Price
SS ASTM A193 B6X Square Nuts
SS ASTM A193 B6X High Temperature Bolts
Stainless Steel ASTM A193 B6X Stud Bolts
ASTM A193 B6X Plain Washer
ASTM A193 B6X Hexagonal Washer
ASTM A193 B6X High Temperature Eye Bolts Dealer
Stainless Steel A193 B6X Machine Screw
ASTM A193 B6X Shoulder Bolt
ASTM A193 B6X J Bolt
ASTM A193 B6X T-Head Bolts
ASTM A193 B6X Stove Bolts
ASTM A193 B6X Nyloc Bolts
ASTM A193 B6X High Temperature Fasteners
ASTM A193 B6X Fasteners Application Area
Our products range of ASTM A193 B6X Fasteners find application in various areas such as: Petro-Chemical Industries, Ship Building Industries, Heavy Engineering Industries, Fertilizer Plants, power Generation Units ( Nuclear, Hydro or Thermal), Civil Industries, Oil Expansion Projects, Off Shore & On Shore Oil Towers, Valves, Vessels, Pumps, Railways, Steel Plants, Civil Construction Industries, Home Fittings etc.
