Table of Content
- What is Phosphorous Bronze Fasteners
- Phosphorous Bronze Fasteners Specification
- Types of Phosphorous Bronze Fasteners
- Phosphorous Bronze Fasteners Price List
- Dimensions Of Phosphorous Bronze Hex Bolts
- Other Types of Phosphorous Bronze Fasteners
- Phosphorous Bronze Fasteners Application Area
- Other Stock of Phosphorous Bronze Fasteners
Phosphorous Bronze Industrial Fasteners, Phosphorous Bronze C51900 Screw, Phosphorous Bronze Washer, Phosphorous Bronze Stud Bolts, Phosphorous Bronze Fastener, Phosphorous Bronze Hex Head Bolt, Phosphorous Bronze Fasteners, Best Deals on Phosphorous Bronze Bolts, Phosphorous Bronze Stud Supplier in India.
Kalpataru Piping Solutions is a renowned manufacturer and exporter of Phosphorous Bronze Fasteners, which are accessible to our valuable customers in different range of diameters. Made-up at par with the set industry guidelines and standards, these Phosphorous Bronze Nuts find vast usage in engineering, petrochemical and construction industries. These Phosphorous Bronze Bolts are having some great features like Smooth surface finish, Corrosion resistance, Sturdy construction, and more. We have in store a wide-ranging range of Phosphorous Bronze Screws for the clients, which are provided by us at economical prices. While manufacturing these Phosphorous Bronze Washers, our professionals make use of high-grade material and follow to the well-defined industry standards and customs. Clients can avail these Phosphorous Bronze Hex Head Nuts in diverse dimensions, standards and grades from us, thus suiting their exact requirements. These Phosphorous Bronze Hex Head Bolts are having some great features like Accurate dimensions, Durable, High tensile strength, and more. We offer these Phosphorous Bronze Hex Head Screws we provide are manufactured by using superior quality of raw material. Phosphorous Bronze Flat Washers is manufactured by using cutting-edge methods so as to make certain their high standards and trouble free usage. Phosphorous Bronze Square Nuts can be availed in different standards, grades and other specifications to the customers, as per their specific demands. Durability, rugged construction, seamless finishing and corrosion resistance are the prominent features of our offered Phosphorous Bronze Square Bolts.
Phosphorous Bronze Star Washer, Phosphorous Bronze C51000 Fasteners, Phosphorous Bronze Lock Washer, Phosphorous Bronze U Bolts Dealer, High Quality Phosphorous Bronze C54400 Hex Head Screw, Phosphorous Bronze Stud, Phosphorous Bronze Socket Head Cap Screw, Phosphorous Bronze Spring Washers, Large Selection of Phosphorous Bronze Hex Nuts, Phosphorous Bronze Machine Screw, Phosphorous Bronze Eye Bolts Exporter.
Phosphorous Bronze Fasteners Specification
DIN And ISO Designations Of Phosphor Bronze Fasteners
| DIN No. of Phosphorous Bronze Fasteners | Description |
|---|---|
| 85 | Slotted Pan Head Machine Screws |
| 84 | Slotted Cheese Head Machine Screws |
| 125A | Flat Washer (without Chamfer) |
| 94 | Cotter Pin |
| 127B | Split Lock Washer |
| 125B | Flat Washer (with Chamfer) |
| 315 | Wing Nut |
| 137B | Spring Wave Washer |
| 911 | Long Arm Hex Key |
| 439B | Machine Screws Hex Nut, Finished Hex Jam Nut |
| 916 | Hex Socket Set Screws |
| 912 | Hex Socket Head Cap Screws |
| 933 | Hex Head Cap Screws Fully Threaded |
| 931 | Hex Head Cap Screws Partially Threaded |
| 939 | Double End Stud |
| 934 | Finished Hex Nut |
| 961 | Hex Head Cap Screws Fully Threaded |
| 960 | Hex Head Cap Screws Partially Threaded |
| 964 | Slotted Oval Head Machine Screws |
| 963 | Slotted Flat Head Machine Screws |
| 966 | Phillips Oval Head Machine Screws |
| 965 | Phillips Flat Head Machine Screws |
| 975 | Threaded Rod |
| 985 | Hex Nylon Insert Lock Nut |
| 980V | Hex Steel Prevailing Torque Lock Nut |
| 6797A | External Tooth Lock Washer |
| 6334 | Rod Coupling Nut |
| 7991 | Hex Flat Socket Head Cap Screws |
| 6912 | Hex Low Socket Head Cap Screws |
| 6797J | Internal Tooth Lock Washer |
| 7985 | Phillips Pan Head Machine Screws |
| 6923 | Hex Flange Nut |
| 6921 | Hex Flange Head Screws |
| ISO 7380 | Hex Button Socket Head Cap Screws |
| ISO 7379 | Hex Socket Head Shoulder Screws |
Types of Phosphorous Bronze Fasteners
Phosphorous Bronze Nuts
Phosphorous Bronze Bolts
Phosphorous Bronze Screws
Phosphorous Bronze Washers
Phosphorous Bronze Stud Bolts
Phosphorous Bronze Anchor Bolts
Phosphorous Bronze Threaded Rod
Phosphorous Bronze Stud
Phosphorous Bronze Fasteners Price List
We offer wide range of industrial Phosphorous Bronze Fasteners that in compliance with IS, BS and DIN standards at best market prices in India. To know more about the latest price of Phosphorous Bronze Fasteners Please Call +91 22-66337137 or Send an Email to info@flangesbolts.com
Dimensions Of Phosphorous Bronze Hex Bolts
| Heavy Hex Bolt Diameter | D | F | C | H | |||||
| Body Diameter | Width Across Flats | Width Across Corners | Height | ||||||
| Max | Basic | Max | Min | Max | Min | Basic | Max | Min | |
| 1/2 | 0.515 | 7/8 | 0.875 | 0.850 | 1.010 | 0.969 | 11/32 | 0.364 | 0.302 |
| 5/8 | 0.642 | 1-1/16 | 1.062 | 1.031 | 1.227 | 1.175 | 27/64 | 0.444 | 0.378 |
| 3/4 | 0.768 | 1-1/4 | 1.250 | 1.212 | 1.443 | 1.383 | 1/2 | 0.524 | 0.455 |
| 7/8 | 0.895 | 1-7/16 | 1.438 | 1.394 | 1.660 | 1.589 | 37/64 | 0.604 | 0.531 |
| 1 | 1.022 | 1-5/8 | 1.625 | 1.575 | 1.876 | 1.796 | 43/64 | 0.700 | 0.591 |
| 1-1/8 | 1.149 | 1-13/16 | 1.812 | 1.756 | 2.093 | 2.002 | 3/4 | 0.780 | 0.658 |
| 1-1/4 | 1.277 | 2 | 2.00 | 1.938 | 2.309 | 2.209 | 27/32 | 0.876 | 0.749 |
| 1-3/8 | 1.404 | 2-3/16 | 2.188 | 2.119 | 2.526 | 2.416 | 29/32 | 0.940 | 0.810 |
| 1-1/2 | 1.531 | 2-3/8 | 2.375 | 2.300 | 2.742 | 2.622 | 1 | 1.036 | 0.902 |
| 1-3/4 | 1.785 | 2-3/4 | 2.750 | 2.662 | 3.175 | 3.035 | 1-5/32 | 1.196 | 1.054 |
| 2 | 2.039 | 3-1/8 | 3.125 | 3.025 | 3.608 | 3.449 | 1-11/32 | 1.388 | 1.175 |
| 2-1/4 | 2.305 | 3-1/2 | 3.500 | 3.388 | 4.041 | 3.862 | 1-1/2 | 1.548 | 1.327 |
| 2-1/2 | 2.559 | 3-7/8 | 3.875 | 3.750 | 4.474 | 4.275 | 1-21/32 | 1.708 | 1.479 |
Phosphorous Bronze Hex Nuts Dimensions
| Hex Nut NB | Across Corners | MAX Thickness | MIN Thickness | MAX Across Flats | MIN Across Flats |
|---|---|---|---|---|---|
| M 8 | 14.38 | 6.8 | 6.44 | 13 | 12.73 |
| M 10 | 17.77 | 8.4 | 8.04 | 16 | 15.73 |
| M 12 | 20.03 | 10.8 | 10.37 | 18 | 17.73 |
| M 14 | 23.35 | 12.8 | 12.1 | 21 | 20.67 |
| M 16 | 26.75 | 14.8 | 14.1 | 24 | 23.67 |
| M 18 | 29.56 | 15.8 | 15.1 | 27 | 26.16 |
| M 20 | 32.95 | 18 | 16.9 | 30 | 29.16 |
| M 22 | 37.29 | 19.4 | 18.1 | 34 | 33 |
| M 24 | 39.55 | 21.5 | 20.2 | 36 | 35 |
| M 27 | 45.2 | 23.8 | 22.5 | 41 | 40 |
| M 30 | 50.85 | 26.6 | 24.3 | 46 | 45 |
| M 33 | 55.37 | 28.7 | 27.4 | 50 | 49 |
| M 36 | 60.79 | 31 | 29.4 | 55 | 53.8 |
| M 39 | 66.44 | 33.4 | 31.8 | 60 | 58.8 |
| M 42 | 71.3 | 34 | 32.4 | 65 | 63.1 |
| M 45 | 76.95 | 36 | 34.4 | 70 | 68.1 |
| M 48 | 82.6 | 38 | 39.4 | 75 | 73.1 |
| M 52 | 88.25 | 42 | 40.4 | 80 | 78.1 |
| M 56 | 93.56 | 45 | 43.4 | 85 | 82.8 |
| M 60 | 99.21 | 48 | 46.4 | 90 | 87.8 |
| M 64 | 104.86 | 51 | 49.1 | 95 | 92.8 |
| M 68 | 110.51 | 54 | 52.1 | 100 | 97.8 |
| M 72 x 6 | 116.16 | 58 | 56.1 | 105 | 102.8 |
| M 76 x 6 | 121.81 | 61 | 59.1 | 110 | 107.8 |
| M 80 x 6 | 127.46 | 64 | 62.1 | 115 | 112.8 |
Phosphorous Bronze Flat Washer Dimensions
| Bolt Size | USS | SAE | ||||
|---|---|---|---|---|---|---|
| OD (in.) | ID (in.) | Thickness | OD (in.) | ID (in.) | Thickness | |
| 1/8 (#6) | – | – | – | 0.375 | 0.156 | .036/.065 |
| 5/32 (#8) | – | – | – | 0.438 | 0.188 | .036/.065 |
| 3/16 (#10) | 0.560 | 0.250 | .036/.065 | 0.500 | 0.220 | .036/.065 |
| 7/32 (#12) | – | – | – | 0.562 | 0.250 | .051/.080 |
| 1/4 (#14) | 0.734 | 0.312 | .051/.080 | 0.625 | 0.281 | .051/.080 |
| 5/16 | 0.875 | 0.375 | .064/.104 | 0.688 | 0.344 | .051/.080 |
| 3/8 | 1.000 | 0.438 | .064/.104 | 0.812 | 0.406 | .051/.080 |
| 7/16 | 1.250 | 0.500 | .064/.104 | 0.922 | 0.469 | .051/.080 |
| 1/2 | 1.375 | 0.562 | .086/.132 | 1.062 | 0.531 | .074/.121 |
| 9/16 | 1.469 | 0.625 | .086/.132 | 1.156 | 0.594 | .074/.121 |
| 5/8 | 1.750 | 0.688 | .108/.160 | 1.312 | 0.656 | .074/.121 |
| 3/4 | 2.000 | 0.812 | .122/.177 | 1.469 | 0.812 | .108/.160 |
| 7/8 | 2.250 | 0.938 | .136/.192 | 1.750 | 0.938 | .108/.160 |
| 1 | 2.500 | 1.062 | .136/.192 | 2.000 | 1.062 | .108/.160 |
| 1 1/8 | 2.750 | 1.250 | .136/.192 | 2.250 | 1.250 | .108/.160 |
| 1 1/4 | 3.000 | 1.375 | .136/.192 | 2.500 | 1.375 | .136/.192 |
| 1 3/8 | 3.250 | 1.500 | .153/.213 | 2.750 | 1.500 | .136/.213 |
| 1 1/2 | 3.500 | 1.625 | .153/.213 | 3.000 | 1.625 | .153/.213 |
| 1 5/8 | 3.750 | 1.750 | .153/.213 | – | – | – |
| 1 3/4 | 4.000 | 1.875 | .153/.213 | – | – | – |
| 1 7/8 | 4.250 | 2.000 | .153/.213 | – | – | – |
| 2 | 4.500 | 2.125 | .153/.213 | – | – | – |
| 2 1/4 | 4.750 | 2.375 | .193/.248 | – | – | – |
| 2 1/2 | 5.000 | 2.625 | .210/.280 | – | – | – |
| 2 3/4 | 5.250 | 2.875 | .228/.310 | – | – | – |
| 3 | 5.500 | 3.125 | .249/.327 | – | – | – |
Other Types of Phosphorous Bronze Fasteners
Phosphorous Bronze Fastener
Phosphorous Bronze Bolts
Phosphorous Bronze Full Threaded Bolt
Phosphorous Bronze Stud Bolts
Phosphorous Bronze C54400 Hex Nuts
Phosphorous Bronze C51000 Washer
Phosphorous Bronze Studs Stockist
Phosphorous Bronze Screw Supplier
Phosphorous Bronze C51900 Wing Nut
Phosphorous Bronze C51900 Lock Washer
Phosphorous Bronze Half Threaded Bolt
Phosphorous Bronze C51900 Machine Bolt
Phosphorous Bronze Anchor Bolt
Phosphorous Bronze Hex Head Screw Exporter
Phosphorous Bronze Locking Nuts
Phosphorous Bronze Punched Washer
Phosphorous Bronze Square Nut
Phosphorous Bronze Flat Washer
Phosphorous Bronze Studbolt
Phosphorous Bronze Nuts Specification
Phosphorous Bronze Socket Head Cap Screw
Phosphorous Bronze C51900 Castle Nuts
Phosphorous Bronze Spring Washer
Phosphorous Bronze Socket Set Screws
Phosphorous Bronze Hex Head Bolt Manufacturer
Phosphorous Bronze C51900 Fender Washer Distributor
Phosphorous Bronze Dome Washer
Phosphorous Bronze Industrial Fastener Price
Phosphorous Bronze C54400 Square Nuts
Phosphorous Bronze Stud Bolts
Phosphorous Bronze Plain Washer
Phosphorous Bronze C51000 Stud
Phosphorous Bronze Stainless Steel Hexagonal Washer
Phosphorous Bronze C51900 Eye Bolts Dealer
Phosphorous Bronze Countersunk Slotted Screw
Phosphorous Bronze Flat Washer
Phosphorous Bronze Stud Bolt
Phosphorous Bronze Coupler Nuts
Phosphorous Bronze Countersunk Slotted Screw
SPhosphorous Bronze Machine Screw
Phosphorous Bronze Fasteners Application Area
Our products range of Phosphorous Bronze Fasteners find application in various areas such as: Petro-Chemical Industries, Ship Building Industries, Heavy Engineering Industries, Fertilizer Plants, power Generation Units ( Nuclear, Hydro or Thermal), Civil Industries, Oil Expansion Projects, Off Shore & On Shore Oil Towers, Valves, Vessels, Pumps, Railways, Steel Plants, Civil Construction Industries, Home Fittings etc.
